ProductStarter
Letrika P/NIS1183
Voltage24 V
Power9.0 kW
OEM P/N11.131.907
MAHLE P/NMS 77
DescriptionAZG4689
No. of pinion teeth11
Module4.233 mm
Distance over two teeth20.56 mm
Outside diameter of pinion57 mm
NotesInsulated ground
Nominal power is 6,5kW according to ISO 8856
Noseless version of starter
Soft start relay
With reduction gear
